JDG-24V/1-SL

SPD according to EN 61643-11 / IEC 61643-11

C2, C3

Nominal voltage U_N

24 V DC

Maximum continuous operating voltage U_C

25 V AC

Maximum continuous operating voltage U_C

36 V DC

Nominal discharge current 8/20 μs I_n

5 kA

Maximum discharge current 8/20 μs I_max

10 kA

Voltage protection level L-L at I_n U_P

50 V

Voltage protection level L-PE at I_n U_P

350 V

Voltage protection level L-L at 1 kV/μs U_P

45 V

Voltage protection level L-PE at 1 kV/μs U_P

500 V

Response time L-L t_A

1 ns

Response time L-PE t_A

100 ns

Impedance R

1.6 Ω

Frequency

4 MHz

Cross section solid

0.08 mm² – 4.00 mm²

Cross section flexible

0.08 mm² – 2.50 mm²

Temperature

-40 °C ... +70 °C

Degree of protection

IP 20
